Inductive Sensor BES

Housing Size M 8 Housing material CuZn, nickel plated Sensing face material PA12 Mounting flush mountable Number of wires 3-wire Switching output PNP Switching element function NO Rated operating distance (sn) 1.5 mm Assured operating distance 0...1.2 mm Rated operational voltage (Ue) 24 DC V Voltage drop max. static 2 V Load current capacity (Ie) 200 mA Short circuit protected yes Protected against polarity reversal yes Ambient temperature min -25 °C Ambient temperature max +70 °C Operating frequency (f) 1000 Hz Degree of protection IP IP67 Connection Cable Approval CE,c_ul_us
